Overview
Inconel 600 is among the finest grades of tubes picking for strong and tough jobs. Since they are the nickel-chromium based alloy; on one side it exhibits excellent corrosion resistance and the other side great temperature tolerance skills. They have resistance to stress-cracking due to chlorine, water effects, and natural decaying. Moreover, it has a good resisting ability to carburization and oxidation environments which has the highest temperate zone till 2000 degree Fahrenheit.
This grade tube is all-in-all versatile and flexible. The specifications of Inconel 600Tubes are governed as per the standards such as ASTM B167, B517, and B516. Additionally, they are available in different types as seamless tubes, ERW, welded, fabricated, and LSAW tubes. Further, they are also found in a variety of formations like round, Weldeds, coiled, U-shaped, pancakes coils, and hydraulic tubes.
Specification
ASTM B167-18 Standard Specification for Nickel-Chromium-Aluminum Alloys (UNS N06699), Nickel-Chromium-Iron Alloys (UNS NO6600, NO6601, NO6603, NO6690, NO6693, NO6025, NO6045, and NO6696), Nickel-Chromium-Cobalt-Molybdenum Alloy (UNS N06617), Nickel-Iron-Chromium-Tungsten Alloy (UNS N06674), and Nickel-Chromium-Molybdenum-Copper Alloy (UNS N06235) Seamless Pipe and Tube.
Equivalent Grades for Inconel Alloy 600 Tubes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Applications
1. Chemical industry
2. Aerospace
3. Heat treating industry
4. Pulp and paper industry
5. Nuclear Engineering
6. Gas turbine components
