Overview

253MA Stainless Steel is Rare Earth Metals (REM) and lean austenitic heat resistant alloy with high strength and outstanding oxidation resistance. 253 MA maintains its heat resistant properties by advanced control of micro alloy additions. The use of rare earth metals in combination with silicon gives superior oxidation resistance up to 2000°F. Nitrogen, carbon and a dispersion of rare earth and alkali metal oxides combine to provide creep rupture strength comparable to the nickel base alloys. A wide variety of components requiring high strength at elevated temperature such as heat exchanger, kilns, stack dampers and oven components are common applications for 253 MA.

253MA S30815 Stainless Steel Tube is a grade combining excellent service properties at high temperature with ease of fabrication. It resists oxidation at temperatures up to 1150°C and can provide superior service to Grade 310 in carbon, nitrogen and sulphur containing atmospheres. Another proprietary designation covering this grade is 2111HTR.

253MA S30815 Stainless Steel contains fairly low nickel content, which gives it some advantage in reducing sulphide atmospheres when compared to high nickel alloys and to Grade 310. The inclusion of high silicon, nitrogen and cerium contents gives the steel good oxide stability, high elevated temperature strength and excellent resistance to sigma phase precipitation.

The austenitic structure gives this grade excellent toughness, even down to cryogenic temperatures. These properties are specified for flat rolled product (stainless steel plate, sheet and coil) as Grade S30815 in ASTM A240/A240M. Similar but not necessarily identical properties are specified for other products such as pipe and bar in their respective specifications.

Specification

253 MA Pipe Specification : ASTM A312, A358 / ASME SA312, SA358
253 MA Tube Specification : ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554
253 MA Pipe Size : 1/8” NB to 24” NB, 1/4” OD to 24” OD sizes.
253 MA Tube Size : 1/2"OD to 8"OD.
Thickness Range : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Outside Finish : 2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Delivery Condition : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request

Chemical Composition

Mechanical Properties

• The yield refers to the transition of ASTM A312 S30815 ASTM A312/A312M from non-uniform elastic state to elastic-plastic state after reaching a certain deformation stress. It marks the beginning of macro-plastic deformation.

• Tensile strength (Rm) refers to the maximum stress that ASTM A312 S30815 ASTM A312/A312M bears before breaking. When the steel yields to a certain extent, its resistance to deformation increases again due to the rearrangement of internal grains. At this time, although the deformation develops rapidly, it can only increase with the increase of stress until the maximum stress is reached. Thereafter, the ASTM A312 S30815 ASTM A312/A312M is ability to resist deformation is obviously reduced, and a large plastic deformation occurs at the weakest point, where the section of the specimen shrinks rapidly, leading to necking until fracture. The maximum stress value of ASTM A312 S30815 ASTM A312/A312M before tensile fracture is called strength limit or tensile strength.

Physical Properties

Applications
